Product Applications
● Semiconductor: Wafer manufacturing/inspection, chip packaging inspection, bonding inspection.
● Display Panel: Manufacturing defects, contamination inspection.
● Industrial/Electronics: Precise inspection of tiny components and circuits on PCBs.
● Medical Devices: Automated microscope observation scenarios.
